50T Pocket Refining Furnace SI Ladle Refining Furnace

1 Set
MOQ
$600,000.00(>=1 Sets)
価格
50T Pocket Refining Furnace SI Ladle Refining Furnace
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
Condition: New
Type: Induction Furnace
Usage: Induction Furnace
Video outgoing-inspection: Provided
Machinery Test Report: Not Available
Marketing Type: Ordinary Product
Warranty of core components: 1 Year
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
Voltage: 750V
Dimension(L*W*H): Customized
Weight (T): 50 T
Power (kW): 600
Warranty: 1 years
Key Selling Points: Long Service Life
Applicable Industries: Machinery Repair Shops, Manufacturing Plant, Construction works
Showroom Location: None
Application: Ladle Refining Furnace
Product Name: 50T MT Ladle Refining Furnace
After-sales Service Provided: Online Support
Melting Material: Molten steel
After Warranty Service: Video technical support
基本情報
お支払配送条件
Packaging Details: normal package naked or according to customers' request
Supply Ability: 1 Set/Sets per Month customized
製品の説明
Specification
Model
50t
Brand
yushun
Place of Origin
WuXi,China
Size
As your capacity
Colour
customized
Product Features
Ladle Refining Furnace
Craft
Metal smelting
CCShape
Customized
Material
As your capacity
Usage
liquid steel refining furnace
Voltage
As your capacity
Product Description

50T MT Ladle Refining Furnace
Compositions and function description, technical parameter of Equipment
1.Steel Ladle 2.Steel ladle trolley and tow cable device
3.Lifting Mechanism 4.Water-cooling furnace Cover
5.Heating Bridge 6.Furnace-cover lifting mechanism
7.Alloy Feeding System 8.Hydraulic syetem
9.Water-cooling syetem 10.Argon syetem
11.Compressing air syetem 12.Transformer
13.Short Net System 14.35KV High Voltage Supply Syetem
15.Low Voltage Electric Control Syetem

1.Steel ladle
Steel ladle is the container for conving the molten steel and also is the funace body of electric-arc heating.The body of steel ladle is welded in 25 mm steel plate and the bottom is welded in 45mm steel plate . Two lofting lugs are set symmetrically at the both sides of steel ladle for hoisting.
The bottom of steel ladle is fitted with slide gate for pouring and bottom argon-blowing inlet. Argon pipeline is towed in by steeel ladle trolley and connected with argon-blowing pipeline bu quick-connector.
2.Tapping Trolley and Towing Cable Device
Steel ladle vehicles are the transport vehicles for steel ladles to reach each working position. Vehicle body is the welding structure of high quality steel plates. The drive mode is the mechanical drive that consists of electric motors, reducer and vehicle wheels. The speed adjusting mode is frequency speed control. Positioning device adopts oil cylinder to be controlled by oil circuit. There is the track clearer on the vehicle body and at both ends of track are installed buffer devices. In a state of accident, the steel ladle can be dragged out by accident guide wheels and the hooks on the vehicle body. At each working positon, the limit switch is used to control the speed adjustment time of steel ladle.
The towing line device provides drive, weighing and argon for the steel ladle vehicles. One end of towing line is fixed on the ground and the other end moving with steel ladle vehicle is fixed on the vehicle body. By this, argon blowing can be ensured for steel ladle in the whole process. The rubber tube of towing line is bundled up with cotton cloth to prevent rubber tude from being burnt by splashing molten steel or steel slag.
Tapping trolley equips with steel ladle weighing device.
Main technical parameters
No
Product name
 numerical value
Tapping Trolley and Towing Cable Device
1
Moving speed of steel ladle vehicle
2～15m/min
2
Drive mode of steel ladle vehicle
 Mechanical, frequency speed control
3
Positioning accuracy of steel ladle car
≤±10mm
4
Load capacity of steel ladle vehicle
≥110t
Lifting Mechanism of Electode
1
Elextrode diameter
Φ350mm(Ultra-high power, graphite electrode)
2
Electrode pitch circle diameter
Φ600mm
3
Maximum stroke of electrode lift
2200mm
4
Electrode lifting speed
(Auto)rise/fall 4 /3 m/min
(Manual)rise/fall 4 /3 m/min
5
Rate of molten steel temperature increase
4℃/min
Furnace-cover lifting mechanism
1
Furnace-cover lifting stroke
400mm
2
Furnace-cover lifting speed
3m/min
